Fe-Ni Soft Magnetic Alloy 1J50 | ||||||||||||
Chemical Component | % | Ni | Fe | C | Cu | P | Si | Mn | Ti | S | ||
Min | 49 | Allowance | 0.15 | 0.3 | ||||||||
Max | 50.5 | Allowance | 0.03 | 0.2 | 0.02 | 0.3 | 0.6 | 0.02 | ||||
Mechanical Property | Electrical Resistivity | Density | Curie Point | Saturation Magnetostrictive Coefficient | Brinell Hardness | Tensile Strength | Yield Strength | Elongation Rate | ||||
Cold-Hardened State | Soft State | Cold-Hardened State | Soft State | Cold-Hardened State | Soft State | Cold-Hardened State | Soft State | |||||
0.45 | 8.2 | 500 | 25 | 170 | 130 | 784 | 451 | 686 | 147 | 3 | 37 | |
Average Expansion Coefficient | Coefficient Of Linear Expansion | |||||||||||
20-100℃ | 20-200℃ | 20-300℃ | 20-400℃ | 20-500℃ | ||||||||
8.9 | 9.27 | 9.2 | 9.2 | 9.4 | ||||||||
1. Magnetic properties: It has a high initial magnetic permeability and maximum magnetic permeability. It exhibits excellent magnetism even in weak magnetic fields, with low hysteresis loss, which can effectively reduce energy loss. For example, in equipment such as transformers and transformers, it can improve the efficiency of electromagnetic conversion.
2. Physical properties: It has good thermal stability, maintaining stable performance within a certain temperature range; at the same time, it has moderate strength and ductility, making it easy to be processed into various shapes.
1. Composition characteristics: Mainly composed of iron, nickel and other elements, the composition ratio has been optimized to ensure its unique performance.
2. Good consistency: The production process ensures the uniformity of the material's performance, with small differences in performance among different batches of products.
1. In the electronic field: Widely used to manufacture the cores of various electronic transformers, chokes, magnetic amplifiers and other components, which can enhance the performance and stability of electronic devices.
2. In instruments and meters: Used to manufacture magnetic components in precision measuring instruments, which helps improve measurement accuracy and reliability.
3. In communication equipment: Used in components such as communication transformers, ensuring the stability and quality of signal transmission.
1. High-performance advantage: Compared with ordinary magnetic materials, Incoloy 1J50 coil has more outstanding magnetic performance in weak magnetic environments, providing more efficient and stable magnetic support for equipment.
2. Flexibility in application: With good processing performance, it can be made into various specifications and shapes according to different needs, adapting to diverse application scenarios.
1. Reliable quality: Customers have reported that the components made of this material have stable performance, and they are less likely to experience performance decline over a long period of use, with a low equipment failure rate.
2. Meeting customized requirements: Manufacturers can provide customized products according to the special requirements of customers, meeting personalized needs in terms of size, performance parameters, etc., and gaining customer recognition.
We understand that each customer has unique needs, so we provide you with personalized services.
1. Size specifications: Customized wire diameters can be produced according to customer requirements, ranging from thinner wires used for precision electronic components to thicker wires suitable for large equipment; at the same time, the diameter, width of the wire roll, and the length of the wire can also be customized as needed to adapt to different application scenarios and installation spaces.
2. Type customization: Although Incoloy 1J50 has specific basic properties, in a certain range, magnetic properties (such as magnetic permeability, remanence, etc.) and mechanical properties (such as strength, hardness, etc.) can be adjusted through process and component ratio adjustments to meet the special material performance requirements of different equipment.
3. Surface treatment customization: Different treatments can be applied to the wire surface according to the usage environment and subsequent processing requirements, such as coating treatment to enhance corrosion resistance or improve welding performance, etc.
4. Packaging form: In addition to the conventional wire reel winding method, special packaging forms can be adopted according to customer requirements, facilitating transportation, storage and use.
