| Hastelloy C-4(UNS NO6455) | |||||||||||||
| chemical component | % | Ni | Cr | Fe | Mo | C | Mn | Si | S | P | Co | Ti | |
| min | allowance | 14 | 14 | ||||||||||
| max | allowance | 18 | 3 | 17 | 0.015 | 1 | 0.08 | 0.03 | 0.04 | 2 | 0.7 | ||
| physical property | Density | 8.6g/cm3 | |||||||||||
| Melting point | 1335-1380 ℃ | ||||||||||||
| The minimum mechanical properties of the alloy at room temperature | Typical mechanical properties | Tensile strength Rm N/mm2 | Yield strength RP0.2N/mm2 | Elongation rate A5 % | Brinell Hardness | ||||||||
| Solution treatment | 690 | 276 | 40 | ≤230 | |||||||||
